Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert 1196-74 HBF

1196-74 HBF

Артикул: 1196-74 HBF

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

050

EPSR Insert included angle

80 Degree

FamilyProducts

80° Rhomboidic insert

GRDMFG Grade manufacturers designation

HBF

GRDPRIO Standard designation of the grade main application

HW-K15

IC Inscribed circle diameter

9.525 mm

ID Technical product number

1196-74 HBF

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

L Cutting edge length

14.3 mm

Materials

K,N,S,H

Name Identifying order number

1196-74 HBF

RE Corner radius

0.5 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

W1 Insert width

9.525 mm

Working process

No working processes available
