1186-25 LW225

Артикул: 1186-25 LW225

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.5 mm

Delivery state valid from

050

EPSR Insert included angle

80 Degree

FamilyProducts

80° Rhomboidic insert

GRDMFG Grade manufacturers designation

LW225

GRDPRIO Standard designation of the grade main application

HW-P25

IC Inscribed circle diameter

8 mm

ID Technical product number

1186-25 LW225

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

L Cutting edge length

11.1 mm

Materials

Name Identifying order number

1186-25 LW225

RE Corner radius

0.3 mm

S Insert thickness

5.3 mm

S1 Insert thickness total

5.3 mm

W1 Insert width

8 mm

Working process

No working processes available
