Главная Каталог продукции Toolunited 15 201-07 - Trigon insert XOMT 060304SN GM40

XOMT 060304SN GM40

Артикул: XOMT 060304SN GM40

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

8 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

XO0603043N

EPSR Insert included angle

84 Degree

FamilyProducts

carbide drilling insert

GRD2ND Standard designation of the grade 2nd application

HC-M35

GRDMFG Grade manufacturers designation

GM40

GRDPRIO Standard designation of the grade main application

HC-P35

IC Inscribed circle diameter

10 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

KRINS Cutting edge angle major

94 Degree

L Cutting edge length

6.62 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

XO0603043N

Materials

P,M

Name Identifying order number

XOMT 060304SN GM40

RE Corner radius

0.4 mm

S Insert thickness

3 mm

S1 Insert thickness total

3 mm

STDDES Standard designation

XOMT060304SN

TCINS Tolerance class insert

Working process

BVB - Drilling
