W05 42180.0204

Артикул: 1483644

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

COMPC Company code

KOG - Komet Group

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

4/24/2012

EPSR Insert included angle

84 Degree

FamilyProducts

WNHX 999

GAN Insert rake angle

18 Degree

GRDMFG Grade manufacturers designation

P40

GRDPRIO Standard designation of the grade main application

HW-P40

IC Inscribed circle diameter

12 mm

ID Technical product number

1483644

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

L - Left

Interface codes

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

7.5 mm

Name Identifying order number

W05 42180.0204

NOI Insert index count

RE Corner radius

0.2 mm

S Insert thickness

4.5 mm

TCINS Tolerance class insert

Working process

No working processes available
