W04 58180.0601

Артикул: 1483645

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

COMPC Company code

KOG - Komet Group

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

4/24/2012

EPSR Insert included angle

84 Degree

FamilyProducts

WNHX 999

GAN Insert rake angle

18 Degree

GRDMFG Grade manufacturers designation

P10

IC Inscribed circle diameter

17.6 mm

ID Technical product number

1483645

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

Interface codes

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

11.5 mm

Name Identifying order number

W04 58180.0601

RE Corner radius

0.6 mm

S Insert thickness

6 mm

TCINS Tolerance class insert

Working process

No working processes available
