Главная Каталог продукции Toolunited 15 405-01 - Double angle collet KT26-M18

KT26-M18

Артикул: 6-01-010976

В наличии

В корзину

Описание

Характеристики

BD Body diameter

41 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

COLST Collet slot type

2 - On two side

COMPC Company code

KOR - Korloy

CZCWS Connection size code

0140

DCB Connection bore diameter

14 mm

DCBN Connection bore diameter minimum

14 mm

DCBX Connection bore diameter maximum

14 mm

Delivery state valid from

6/4/2014

DIN

KOR-KT26

FamilyProducts

Collet KT

ID Technical product number

6-01-010976

Interface codes

J6 /

ISYC Subclass

405-01 - Double angle collet

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CZCWS Connection size code

0140

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01402115

LOC-03 CZCMS Connection size code

0260

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KOR-KT26

LSCX Clamping length maximum

25 mm

Name Identifying order number

KT26-M18

OAL Overall length

76 mm

SEALP Sealing

1 - With sealing

SZID Size identification

KT26
