Главная Каталог продукции Toolunited 15 405-01 - Double angle collet 20ERTC055043M

20ERTC055043M

Артикул: 1551135

В наличии

В корзину

Описание

Характеристики

BD Body diameter

21 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COMPC Company code

KH - Kennametal

CZCWS Connection size code

0055

DCB Connection bore diameter

5.5 mm

DCBN Connection bore diameter minimum

5.5 mm

Delivery state valid from

1/4/2011

DFC Functional diameter

20 mm

DIN

SZD02000295

FamilyProducts

COLLET ERTC

ID Technical product number

1551135

Interface codes

J6 /

ISYC Subclass

405-01 - Double angle collet

LCOL Collet length

31.5 mm

LDG Gauge diameter distance

6.36 mm

LFSF Distance to face

4.8 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0055

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL00552105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SZD Collet adapter DIN / ISO

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0200

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SZD02000295

LSCX Clamping length maximum

18 mm

Name Identifying order number

20ERTC055043M

OAL Overall length

31.5 mm

SEALP Sealing

1 - With sealing

STDNO Standard

DIN6499

SZID Size identification

TA Taper angle 1

16 Degree

TA Taper angle 2

30 Degree

UNNO Unified number

428E
