Главная Каталог продукции Toolunited 15 405-08 - Cylindrical clamping sleeve MN5428-03

MN5428-03

MN5428-03 MN5428-03

MN5428-03

Mapal
Артикул: 30251083
В наличии
В корзину
Описание
Характеристики
BD Body diameter
30 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
COLST Collet slot type
1 - On one side
COMPC Company code
MP - Mapal
CZCWS Connection size code
0050
DCB Connection bore diameter
5 mm
DCBN Connection bore diameter minimum
5 mm
DCBX Connection bore diameter maximum
5 mm
Delivery state valid from
2/17/2012
DIN
ZYL02500115
FamilyProducts
sleeve
ID Technical product number
30251083
Interface codes
J6 /
ISYC Subclass
405-08 - Cylindrical clamping sleeve
LCOL Collet length
56 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0050
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL00500115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02500115
LSCX Clamping length maximum
29 mm
Name Identifying order number
MN5428-03
OAL Overall length
60 mm
SEALP Sealing
1 - With sealing
