Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary PH300/09/12

PH300/09/12

Артикул: PH300/09/12

В наличии

В корзину

Описание

Характеристики

BD Body diameter

59 mm

BD Body diameter 2

68 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COMPC Company code

MP - Mapal

CZCWS Connection size code

0250

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/1/2009

DIN

ZYV03000115

FamilyProducts

Pendelhalter für Zylinderschaft mit Mitnahmefläche

ID Technical product number

PH300/09/12

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

LB Body length 1

111 mm

LB Length 2

9.5 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0250

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL02500115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0300

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV03000115

LPR Protruding length

111 mm

Name Identifying order number

PH300/09/12

OAL Overall length

166 mm

Rotation Rotation indicator

0 - stationary tool
