EV2525R-112

Артикул: 1-06-040423

В наличии

В корзину

Описание

Характеристики

ADJHT Adujstment height property

CCFWS Connection code form

CCONWS Connection count workpiece side

CCSWS Connection code style

CCTWS Connection code type

VKT

CCUWS Connection code unit base

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KOR - Korloy

CXSC Coolant exit style code

0 - Without coolant exit

CZCWS Connection size code

2525

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/4/2014

DIN

HSK06300785

FamilyProducts

EV2525R/L-112

HAND Cutting direction

L - Left

HF Functional height

25 mm

ID Technical product number

1-06-040423

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

LB Body length 1

45 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

VKT Square mounting

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

2525

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

VKT25250105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

HSK Hollow taper shank

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0630

LOC-03 DCONMS Diameter

63 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK06300785

LPR Protruding length

150 mm

LSCN Clamping length minimum

77 mm

LSCX Clamping length maximum

77 mm

Name Identifying order number

EV2525R-112

RADH Radial height

53 mm

RADW Radial width

37.75 mm

Rotation Rotation indicator

0 - stationary tool

WF Functional width

12.75 mm
