Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary DIN69880 30 HYDRO 25X100

DIN69880 30 HYDRO 25X100

DIN69880 30 HYDRO 25X100

DIN69880 30 HYDRO 25X100

Iscar
Артикул: 4559269
В наличии
В корзину
Описание
Характеристики
BD Body diameter
50 mm
BD Body diameter 2
68 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0250
DCINTF Interference cutting diameter
46 mm
DCONWS Diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2014
DIN
ZYV03000115
FamilyProducts
DIN69880 30 HYDRO 25X100
HAND Cutting direction
N - Neutral
ID Technical product number
4559269
Interface codes
J6 /
ISYC Subclass
401-02 - Converter, stationary
LB Body length 1
78 mm
LB Length 2
16 mm
LF Functional length
100 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0250
LOC-01 DCONWS Diameter
25 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL02500115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYV cylindrical shank VDI type (serrated)
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0300
LOC-03 DCONMS Diameter
30 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYV03000115
LPR Protruding length
94 mm
LS Shank length
55 mm
LSCN Clamping length minimum
54 mm
LSCX Clamping length maximum
85 mm
Name Identifying order number
DIN69880 30 HYDRO 25X100
