Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary A2110-BT45-26R-080-P

A2110-BT45-26R-080-P

A2110-BT45-26R-080-P A2110-BT45-26R-080-P A2110-BT45-26R-080-P

A2110-BT45-26R-080-P

Walter
Артикул: 6838292
В наличии
В корзину
Описание
Характеристики
CCFWS Form
01
CCSWS Style
5
CCTWS Type
PMW
CCUWS Unit base
8
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Size code
0260
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
FLCB4AN0285
FamilyProducts
BMT adaptor – Parting blades A2110-BT...-P
HAND Cutting direction
R - Right
HF Functional height
21 mm
ID Technical product number
6838292
Interface codes
J6 / J61
ISO
FLC02CB4AN$$$$
ISYC Subclass
401-02 - Converter, stationary
KAP Kappa
0 Degree
LB Body length 1
41 mm
LF Functional length
80 mm
LOC-01 CCFWS Form
01
LOC-01 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Type
PMW Prism mounting WOHLHAUPTER
LOC-01 CCUWS Unit base
8 non-dimensional size
LOC-01 CZCWS Size code
0260
LOC-01 ISO
PMW01C0260****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
PMW02600185
LOC-02 CCFWS Form
01
LOC-02 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-02 CCTWS Type
PMW Prism mounting WOHLHAUPTER
LOC-02 CCUWS Unit base
8 non-dimensional size
LOC-02 CZCWS Size code
0260
LOC-02 ISO
PMW01C026R****
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
PMW026R0185
LOC-03 CCFMS Form
02
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
FLC Flange mounting SANDVIK Coromant
LOC-03 CCUMS Unit base
8 non-dimensional size
LOC-03 CZCMS Size code
B4AN
LOC-03 DCONMS Diameter
26 mm
LOC-03 ISO
FLC02CB4AN$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FLCB4AN0285
LPR Protruding length
80 mm
Name Identifying order number
A2110-BT45-26R-080-P
OAH Overall height
84 mm
OAL Overall length
80 mm
OAW Overall width
109 mm
WF Functional width
60.5 mm
WT Weight of item
1.99 kg
