Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary A08 71590

A08 71590

Артикул: 1486838

В наличии

В корзину

Описание

Характеристики

BD Body diameter

63 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

HSK

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0630

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DIN

ZYV05000115

FamilyProducts

KomLoc NC-Aufnahme gerade

HAND Cutting direction

L - Left

ID Technical product number

1486838

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

LB Body length 1

65 mm

LF Functional length

95 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

HSK Hollow taper shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0630

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

HSK06300195

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV05000115

LPR Protruding length

95 mm

LSCN Clamping length minimum

0 mm

Name Identifying order number

A08 71590

OAL Overall length

173 mm

Rotation Rotation indicator

0 - stationary tool

WT Weight of item

5.6 kg
