Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary A08 60350

A08 60350

Артикул: 1482590

В наличии

В корзину

Описание

Характеристики

BD Body diameter

50 mm

BD Body diameter 2

0 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

HSK

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0500

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

FamilyProducts

Vierkantaufnahme

HAND Cutting direction

N - Neutral

ID Technical product number

1482590

Interface codes

ISYC Subclass

401-02 - Converter, stationary

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

HSK Hollow taper shank

LOC-01 CZCWS Connection size code

0500

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

HSK05000195

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LSCN Clamping length minimum

0 mm

Name Identifying order number

A08 60350

OAL Overall length

127 mm

Rotation Rotation indicator

0 - stationary tool

WT Weight of item

2.8 kg
