Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary C5-LC2085-32130-20M

C5-LC2085-32130-20M

C5-LC2085-32130-20M C5-LC2085-32130-20M C5-LC2085-32130-20M

C5-LC2085-32130-20M

Walter
Артикул: 5029302
В наличии
В корзину
Описание
Характеристики
CCFWS Form
01
CCSWS Style
5
CCTWS Type
CCS
CCUWS Unit base
9
CNSC Coolant entry style code
2 - With Coolant entry, radial
COMPC Company code
W - Walter
CXSC Coolant exit style code
2 - With Coolant exit, radial
CZCWS Size code
0500
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
VKT40200135
FamilyProducts
Clamping units Typ 2080 / 2085
HAND Cutting direction
L - Left
HF Functional height
31.75 mm
ID Technical product number
5029302
Interface codes
J6 / J61
ISO
VKT01B4020$$$$
ISYC Subclass
401-02 - Converter, stationary
KAP Kappa
0 Degree
LF Functional length
130.5 mm
LOC-01 CCFWS Form
01
LOC-01 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Type
CCS Coromant Capto System SANDVIK
LOC-01 CCUWS Unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Size code
0500
LOC-01 ISO
CCS01C0500****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
CCS05000195
LOC-02 CCFWS Form
01
LOC-02 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-02 CCTWS Type
CCS Coromant Capto System SANDVIK
LOC-02 CCUWS Unit base
9 non-dimensional size with coolant
LOC-02 CZCWS Size code
0500
LOC-02 ISO
CCS02C0500****
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
CCS05000295
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
VKT Square mounting
LOC-03 CCUMS Unit base
3 Inch with coolant
LOC-03 CZCMS Size code
4020
LOC-03 ISO
VKT01B4020$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT40200135
LPR Protruding length
130.56 mm
Name Identifying order number
C5-LC2085-32130-20M
OAH Overall height
72 mm
OAL Overall length
130.5 mm
OAW Overall width
64 mm
STDNO Standard
ISO26623-2
WF Functional width
32 mm
WT Weight of item
3.48 kg
