Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary 319001 50

319001 50

Артикул: 319001 50

В наличии

В корзину

Описание

Характеристики

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

VKT

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

HOG - Hoffmann Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/11/2017

DHD Drop head design

0 - Normal

DIN

ZYV05000115

FamilyProducts

GARANT eco-toolholder Form B1, radial right-hand, short

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

LF Functional length

33 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

VKT Square mounting

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

VKT25250105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV05000115

LPR Protruding length

50 mm

LS Shank length

78 mm

Name Identifying order number

319001 50

OAH Overall height

83 mm

OAL Overall length

133 mm

OAW Overall width

100 mm

RADH Radial height

48 mm

RADW Radial width

48 mm

WT Weight of item

3.74 kg
