Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary 12638346800

12638346800

Артикул: 12638346800

В наличии

В корзину

Описание

Характеристики

ADJHT Adujstment height property

CCFWS Form

CCONWS Connection count workpiece side

CCSWS Style

CCTWS Type

UTS

CCUWS Unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state

KA - Unknown

DHD Drop head design

2 - Normal and overhead

DIN

ZYV04000115

FamilyProducts

UTS basic holder, driven

ID Technical product number

12638346800

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

KAP Kappa

0 Degree

LAM Actuation method

0 - manual clamping

LF Functional length

70 mm

LOC-01 CCFWS Form

LOC-01 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Type

UTS Widaflex connection WIDIA

LOC-01 CCUWS Unit base

9 non-dimensional size with coolant

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

UTS04000195

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV04000115

LPR Protruding length

112 mm

Name Identifying order number

12638346800

OAH Overall height

152 mm

OAL Overall length

191 mm

OAW Overall width

84 mm

RADH Radial height

42 mm

RADW Radial width

42 mm

Rotation Rotation indicator

0 - stationary tool
