Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary 12559115000

12559115000

Артикул: 12559115000

В наличии

В корзину

Описание

Характеристики

ADJHT Adujstment height property

BD Body diameter

68 mm

BD Body diameter 2

98 mm

CCONWS Connection count workpiece side

CCSWS Style

CCTWS Type

ZYL

CCUWS Unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state valid from

178.3 €

DHD Drop head design

2 - Normal and overhead

DIN

ZYV05000115

FamilyProducts

Holder for internal turning

ID Technical product number

12559115000

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

KAP Kappa

0 Degree

LAM Actuation method

0 - manual clamping

LOC-01 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Type

ZYL cylindrical shank

LOC-01 CCUWS Unit base

1 Metric with coolant

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL00800106ZYL02700106

LOC-02 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-02 CCTWS Type

ZYL cylindrical shank

LOC-02 CCUWS Unit base

1 Metric with coolant

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

ZYL00800116ZYL02700106

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV05000115

LPR Protruding length

90 mm

Name Identifying order number

12559115000

Rotation Rotation indicator

0 - stationary tool

STDNO Standard

DIN69880--E2
