Главная Каталог продукции Toolunited 15 401-02 - Converter, stationary 12555206300

12555206300

Артикул: 12555206300

В наличии

В корзину

Описание

Характеристики

ADJHT Adujstment height property

CCFWS Form

CCONWS Connection count workpiece side

CCSWS Style

CCTWS Type

VKT

CCUWS Unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Size code

3225

DCP Data chip provision

0 - Without data chip

Delivery state valid from

268.9 €

DHD Drop head design

1 - overhead

DIN

ZYV06000115

FamilyProducts

Holder for external turning, long

HF Functional height

32 mm

ID Technical product number

12555206300

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

KAP Kappa

0 Degree

LAM Actuation method

0 - manual clamping

LF Functional length

30 mm

LOC-01 CCFWS Form

LOC-01 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Type

VKT Square mounting

LOC-01 CCUWS Unit base

0 Metric

LOC-01 CZCWS Size code

3225

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

VKT32250105

LOC-02 CCFWS Form

LOC-02 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-02 CCTWS Type

VKT Square mounting

LOC-02 CCUWS Unit base

0 Metric

LOC-02 CZCWS Size code

3225

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

VKT32320105

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0600

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV06000115

LPR Protruding length

60 mm

Name Identifying order number

12555206300

OAW Overall width

145 mm

RADH Radial height

62.5 mm

RADW Radial width

82.5 mm

Rotation Rotation indicator

0 - stationary tool

STDNO Standard

DIN69880--B7
