A20 00280

Артикул: 1474598

В наличии

В корзину

Описание

Характеристики

ADJBY Adjustment property

0 - Adjustment not possible

BD Body diameter

100 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ABS

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

1000

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DF Flange diameter

100 mm

DIN

ABS10000115

FamilyProducts

Verlängerung

HAND Cutting direction

N - Neutral

ID Technical product number

1474598

Interface codes

J6 /

ISYC Subclass

401-03 - Extender

LB Body length 1

160 mm

LF Functional length

160 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ABS KOMET ABS connection

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

1000

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ABS10000115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ABS KOMET ABS connection

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

1000

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ABS10000115

LPR Protruding length

160 mm

Name Identifying order number

A20 00280

OAL Overall length

215 mm

PENDP Pendulum property

0 - Without

Rotation Rotation indicator

1 - rotating tool

WT Weight of item

9.7 kg
