Главная Каталог продукции Toolunited 15 401-00 - Adaptive item converter, extender, reducer unspecified XS7160171T4R01

XS7160171T4R01

Артикул: 3212178

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state

LL - Stock limited

DIN

ZYL02000115

FamilyProducts

Holder reaming head 1,5D / 3D / 5D / 8D

HAND Cutting direction

N - Neutral

ID Technical product number

3212178

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

IL-K-XT7

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000115

LPR Protruding length

170.6 mm

Name Identifying order number

XS7160171T4R01

OAL Overall length

220.6 mm

WT Weight of item

0.33 kg
