Главная Каталог продукции Toolunited 15 401-00 - Adaptive item converter, extender, reducer unspecified 640.01.005

640.01.005

Артикул: 1484379

В наличии

В корзину

Описание

Характеристики

BD Body diameter

23.4 mm

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DIN

ZYL02500115

FamilyProducts

REAMAX- Halter kurz 3xD

HAND Cutting direction

N - Neutral

ID Technical product number

1484379

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

67005

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

25 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02500115

LPR Protruding length

95 mm

Name Identifying order number

640.01.005

OAL Overall length

151 mm

Rotation Rotation indicator

1 - rotating tool

STDNO Standard

DIN 1835 A

TCDCONMS ISO-tolerance class shank diameter

WT Weight of item

0.46 kg
