Главная Каталог продукции Toolunited 15 401-04 - Reducer, primary design CAB M12M16

CAB M12M16

Артикул: 3110643

В наличии

В корзину

Описание

Характеристики

BD Body diameter

21 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

SAI

CCUWS Connection code unit base

COMPC Company code

IS - Iscar

CZCWS Connection size code

0120

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2014

DIN

SAI01600215

FamilyProducts

CAB M12M16

HAND Cutting direction

R - Right

ID Technical product number

3110643

Interface codes

J6 / J61

ISO

SAI02G1600$$$$

ISYC Subclass

401-04 - Reducer, primary design

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

SAI Screw mounting ISCAR

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0120

LOC-01 ISO

SAI02G1200$$$$

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

SAI01200215

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAI Screw mounting ISCAR

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 ISO

SAI02G1600$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAI01600215

LPR Protruding length

50 mm

LS Shank length

25 mm

Name Identifying order number

CAB M12M16

OAL Overall length

75 mm
