Главная Каталог продукции Toolunited 15 401-04 - Reducer, primary design A20 10770

A20 10770

Артикул: 1474631

В наличии

В корзину

Описание

Характеристики

BD Body diameter

80 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ABS

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0800

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DIN

ABS12500115

FamilyProducts

Reduzierung

HAND Cutting direction

N - Neutral

ID Technical product number

1474631

Interface codes

J6 /

ISYC Subclass

401-04 - Reducer, primary design

LB Body length 1

50 mm

LF Functional length

100 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ABS KOMET ABS connection

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0800

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ABS08000115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ABS KOMET ABS connection

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

1250

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ABS12500115

LPR Protruding length

100 mm

LSCN Clamping length minimum

0 mm

Name Identifying order number

A20 10770

OAL Overall length

170 mm

Rotation Rotation indicator

1 - rotating tool

WT Weight of item

8 kg
