TUNGBORE HSK A 63 EM25

TUNGBORE HSK A 63 EM25 TUNGBORE HSK A 63 EM25

TUNGBORE HSK A 63 EM25

Tungaloy
Артикул: TUNGBORE HSK A 63 EM25
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
1 - Radial adjustment possible
ADJHT Adujstment height property
0
BD Body diameter
72 mm
BD Body diameter 2
70 mm
BLDEV Balancing device
0
CCFWS Form
13
CCONWS Connection count workpiece side
1
CCSWS Style
5
CCTWS Type
ZYL
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
TT - Tungaloy
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Size code
0250
DCONWS Diameter
25 mm
DCONXWS Connection diameter max
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/27/2012
DIN
HSK06300195
FamilyProducts
toolholder, radially adjustable, HSK type
HAND Cutting direction
N - Neutral
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LAM Actuation method
0 - manual clamping
LB Body length 1
71 mm
LB Length 2
116 mm
LOC-01 CCFWS Form
13
LOC-01 CCSWS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Type
ZYL cylindrical shank
LOC-01 CZCWS Size code
0250
LOC-01 DCONWS Diameter
25 mm
LOC-01 DCONXWS Connection diameter max
25 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL02501315
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
HSK Hollow taper shank
LOC-03 CCUMS Unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Size code
0630
LOC-03 DCONMS Diameter
63 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR Protruding length
142 mm
LSCX Clamping length maximum
71 mm
Name Identifying order number
TUNGBORE HSK A 63 EM25
PENDP Pendulum property
0 - Without
Rotation Rotation indicator
1 - rotating tool
TCMC Tool change method code
0 - manual tool change
