Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric SK50-DTN12-100

SK50-DTN12-100

SK50-DTN12-100 SK50-DTN12-100

SK50-DTN12-100

Korloy
Артикул: SK50-DTN12-100
В наличии
В корзину
Описание
Характеристики
BD Body diameter
39 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SWB
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOR - Korloy
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0190
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/4/2014
DIN
SKG05001085
DLN Diameter lock nut
32 mm
FamilyProducts
SK-DTN
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
100 mm
LCOMP Length compensation for compression
4 mm
LF Functional length
75 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SWB Quick change adapter BILZ
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0190
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SWB01900105
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05001085
LPR Protruding length
75 mm
LTENS Length compensation for tension
10 mm
Name Identifying order number
SK50-DTN12-100
Rotation Rotation indicator
1 - rotating tool
STDLET Standard letter to the standard number
A/B
STDNO Standard
DIN69871-1
WT Weight of item
3.8 kg
