Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric SC25M12S10-BT40

SC25M12S10-BT40

SC25M12S10-BT40 SC25M12S10-BT40 SC25M12S10-BT40 SC25M12S10-BT40

SC25M12S10-BT40

Mitsubishi Materials
Артикул: 454758
В наличии
В корзину
Описание
Характеристики
BD Body diameter
23.5 mm
BLQ Balance quality code
23,5
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SAD
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
MI - Mitsubishi Materials
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0120
DCONWS Diameter
12 mm
Delivery state valid from
4/1/2022
DIN
SKG04005195
FamilyProducts
spare parts
HAND Cutting direction
R - Right
ID Technical product number
454758
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
10 mm
LF Functional length
10 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SAD Screw mounting
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0120
LOC-01 DCONWS Diameter
12 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAD01200115
LOC-03 CCFMS Connection code form
51
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005195
LPR Protruding length
37 mm
Name Identifying order number
SC25M12S10-BT40
