Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric MN5266-18-K

MN5266-18-K

MN5266-18-K MN5266-18-K

MN5266-18-K

Mapal
Артикул: 30251150
В наличии
В корзину
Описание
Характеристики
BD Body diameter
40 mm
BD Body diameter 2
50 mm
BLQ Balance quality code
G6,3
CCFWS Connection code form
01
CCONWS Connection count workpiece side
1
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
MP - Mapal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0180
DCONWS Diameter
18 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
2/17/2012
DIN
HSK06300195
FamilyProducts
hydraulic chuck
HAND Cutting direction
N - Neutral
ID Technical product number
30251150
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
105 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0180
LOC-01 DCONWS Diameter
18 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01800115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR Protruding length
150 mm
LSCN Clamping length minimum
39 mm
LSCX Clamping length maximum
49 mm
Name Identifying order number
MN5266-18-K
Rotation Rotation indicator
1 - rotating tool
RPMX Rotational speed maximum
15000 1/min
WT Weight of item
2.1 kg
