Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric KM40RDC1390

KM40RDC1390

Артикул: 1135808

В наличии

В корзину

Описание

Характеристики

BD Body diameter

43 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COMPC Company code

KH - Kennametal

DCONWS Diameter

1 mm

DCONXWS Connection diameter max

13 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/4/2011

DIN

KMT04000195

FamilyProducts

DRILL CHUCK

ID Technical product number

1135808

Interface codes

J6 /

ISYC Subclass

401-01 - Converter, rotationally symmetric

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 DCONWS Diameter

1 mm

LOC-01 DCONXWS Connection diameter max

13 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KMT04000195

LPR Protruding length

98 mm

Name Identifying order number

KM40RDC1390

Rotation Rotation indicator

1 - rotating tool
