Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric HSK63A-DSC32-160

HSK63A-DSC32-160

HSK63A-DSC32-160 HSK63A-DSC32-160 HSK63A-DSC32-160

HSK63A-DSC32-160

Korloy
Артикул: 6-01-019276
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
BD Body diameter
44 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOR - Korloy
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0320
DCONWS Diameter
32 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/4/2014
DF Flange diameter
52.5 mm
DIN
HSK06300185
FamilyProducts
HSK-DSC
HAND Cutting direction
N - Neutral
ID Technical product number
6-01-019276
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
160 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0320
LOC-01 DCONWS Diameter
32 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL03200105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300185
LPR Protruding length
160 mm
LSCN Clamping length minimum
52 mm
LSCX Clamping length maximum
62 mm
Name Identifying order number
HSK63A-DSC32-160
PENDP Pendulum property
0 - Without
Rotation Rotation indicator
1 - rotating tool
TA Taper angle
4 Degree
WT Weight of item
1.2 kg
