Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric HSK100AEM50130M

HSK100AEM50130M

HSK100AEM50130M HSK100AEM50130M

HSK100AEM50130M

Kennametal
Артикул: 1322096
В наличии
В корзину
Описание
Характеристики
BD Body diameter
100 mm
CCFWS Connection code form
13
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0500
DCONWS Diameter
50 mm
DCONXWS Connection diameter max
50 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/4/2011
DIN
HSK10000195
FamilyProducts
ENDMILL ADAPTOR EM
ID Technical product number
1322096
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Length 2
78 mm
LOC-01 CCFWS Connection code form
13
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0500
LOC-01 DCONWS Diameter
50 mm
LOC-01 DCONXWS Connection diameter max
50 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL05001315
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
1000
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000195
LPR Protruding length
130 mm
Name Identifying order number
HSK100AEM50130M
Rotation Rotation indicator
1 - rotating tool
