Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric DV50EM16150M

DV50EM16150M

Артикул: 1189666

В наличии

В корзину

Описание

Характеристики

BD Body diameter

48 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

CNSC Coolant entry style code

7 - Coolant entry, decentral and axially concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0160

DCONWS Diameter

16 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/4/2011

DIN

SKG05001795

FamilyProducts

ENDMILL ADAPTOR WELDON EM

ID Technical product number

1189666

Interface codes

J6 /

ISYC Subclass

401-01 - Converter, rotationally symmetric

LB Body length 1

130.9 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0160

LOC-01 DCONWS Diameter

16 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01601015

LOC-02 DCONWS Diameter

16 mm

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

KH-FVSS B16

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG05001795

LPR Protruding length

150 mm

LSCN Clamping length minimum

53 mm

Name Identifying order number

DV50EM16150M

PENDP Pendulum property

0 - Without

Rotation Rotation indicator

1 - rotating tool

STDNO Standard

DIN69871

THSZMS Connection thread nominal size machine side

M24

WT Weight of item

4.13 kg
