Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric DIN69871 50 DC B18X26

DIN69871 50 DC B18X26

DIN69871 50 DC B18X26 DIN69871 50 DC B18X26

DIN69871 50 DC B18X26

Iscar
Артикул: 4541011
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
01
CCSWS Connection code style
0
CCTWS Connection code type
BFA
CCUWS Connection code unit base
8
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0180
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2014
DIN
SKG05001085
FamilyProducts
DIN69871 50 DC B18X26
HAND Cutting direction
N - Neutral
ID Technical product number
4541011
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
BFA Drill chuck taper
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0180
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
BFA01800180
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05001085
LPR Protruding length
26 mm
Name Identifying order number
DIN69871 50 DC B18X26
