Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric BT50HPSS32100M

BT50HPSS32100M

BT50HPSS32100M BT50HPSS32100M

BT50HPSS32100M

Kennametal
Артикул: BT50HPSS32100M
В наличии
В корзину
Описание
Характеристики
BD Body diameter
68 mm
BD Body diameter 2
32 mm
CCFWS Connection code form
05
CCSWS Connection code style
5
CCTWS Connection code type
SZK
CCUWS Connection code unit base
9
COMPC Company code
KH - Kennametal
CZCWS Connection size code
0320
DCONXWS Connection diameter max
32 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG05005195
FamilyProducts
COLLET CHUCK POWERGRIP
ID Technical product number
BT50HPSS32100M
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
05
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZK
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0320
LOC-01 DCONXWS Connection diameter max
32 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZK03200595
LOC-03 CCFMS Connection code form
51
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05005195
LPR Protruding length
100 mm
Name Identifying order number
BT50HPSS32100M
Rotation Rotation indicator
1 - rotating tool
