Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric BT40REM16150M

BT40REM16150M

BT40REM16150M BT40REM16150M

BT40REM16150M

Kennametal
Артикул: BT40REM16150M
В наличии
В корзину
Описание
Характеристики
BD Body diameter
40 mm
BD Body diameter 2
127 mm
CCFWS Connection code form
13
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
COMPC Company code
KH - Kennametal
CZCWS Connection size code
0160
DCONWS Diameter
16 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG04005695
FamilyProducts
ROTARY COOLANT ADAPTOR ENDMIL
ID Technical product number
BT40REM16150M
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
13
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0160
LOC-01 DCONWS Diameter
16 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01601315
LOC-02 DCONWS Diameter
16 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
KH-FVSS B16
LOC-03 CCFMS Connection code form
56
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005695
LPR Protruding length
150 mm
Name Identifying order number
BT40REM16150M
Rotation Rotation indicator
1 - rotating tool
RPMX Rotational speed maximum
6500 1/min
