Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A60 13231

A60 13231

A60 13231 A60 13231 A60 13231

A60 13231

Komet Group
Артикул: 1496856
В наличии
В корзину
Описание
Характеристики
BD Body diameter
25 mm
BD Body diameter 2
25 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ABS
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0250
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
SKG05000695
FamilyProducts
Steilkegelaufnahme
HAND Cutting direction
N - Neutral
ID Technical product number
1496856
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
100 mm
LCOMP Length compensation for compression
0 mm
LF Functional length
145 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ABS KOMET ABS connection
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0250
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ABS02500115
LOC-03 CCFMS Connection code form
06
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05000695
LPR Protruding length
145 mm
LSCN Clamping length minimum
0 mm
Name Identifying order number
A60 13231
OAL Overall length
246.8 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
JIS B 6339
WT Weight of item
4.5 kg
