Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A40 07250

A40 07250

A40 07250 A40 07250

A40 07250

Komet Group
Артикул: 1496941
В наличии
В корзину
Описание
Характеристики
BD Body diameter
58 mm
CCFWS Connection code form
01
CCSWS Connection code style
0
CCTWS Connection code type
FDA
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0320
DCONWS Diameter
32 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ABS10000205
FamilyProducts
Fräseraufnahme Ø32
HAND Cutting direction
N - Neutral
ID Technical product number
1496941
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
16 mm
LF Functional length
40 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
FDA Milling arbor mounting
LOC-01 CZCWS Connection size code
0320
LOC-01 DCONWS Diameter
32 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FDA03200100
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ABS KOMET ABS connection
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
1000
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ABS10000205
LPR Protruding length
40 mm
LSCN Clamping length minimum
0 mm
LSCX Clamping length maximum
16 mm
Name Identifying order number
A40 07250
OAL Overall length
121 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN 6358
