Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A32 40070

A32 40070

A32 40070 A32 40070 A32 40070

A32 40070

Komet Group
Артикул: 1475132
В наличии
В корзину
Описание
Характеристики
BD Body diameter
65 mm
CCFWS Connection code form
10
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0250
DCONWS Diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ABS05000115
FamilyProducts
Spannfutter Weldon Ø25
HAND Cutting direction
N - Neutral
ID Technical product number
1475132
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
75 mm
LOC-01 CCFWS Connection code form
10
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0250
LOC-01 DCONWS Diameter
25 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL02501015
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ABS KOMET ABS connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ABS05000115
LPR Protruding length
75 mm
LSCX Clamping length maximum
60 mm
Name Identifying order number
A32 40070
OAL Overall length
106 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN 1835 B
WT Weight of item
1.85 kg
