Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A30 31401

A30 31401

A30 31401 A30 31401 A30 31401

A30 31401

Komet Group
Артикул: 1475064
В наличии
В корзину
Описание
Характеристики
BD Body diameter
42 mm
CCFWS Connection code form
13
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0140
DCINTF Interference cutting diameter
30 mm
DCONWS Diameter
14 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ABS04000115
FamilyProducts
Spannfutter Whistle Notch Ø14
HAND Cutting direction
N - Neutral
ID Technical product number
1475064
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
65 mm
LOC-01 CCFWS Connection code form
13
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0140
LOC-01 DCONWS Diameter
14 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01401315
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ABS KOMET ABS connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ABS04000115
LPR Protruding length
65 mm
LSCN Clamping length minimum
35 mm
LSCX Clamping length maximum
45 mm
Name Identifying order number
A30 31401
OAL Overall length
91 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN 1835 E
TA Taper angle
30 Degree
WT Weight of item
0.75 kg
