Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A25 06280

A25 06280

A25 06280 A25 06280

A25 06280

Komet Group
Артикул: 1485266
В наличии
В корзину
Описание
Характеристики
A1 CHW Chamfer width at length 1
44.47172 mm
BD Body diameter
27 mm
BD Body diameter 2
34 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0140
DCONWS Diameter
14 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
SKG04001195
FamilyProducts
Schrumpffutter 999
HAND Cutting direction
N - Neutral
ID Technical product number
1485266
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0140
LOC-01 DCONWS Diameter
14 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01400115
LOC-03 CCFMS Connection code form
11
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04001195
LPR Protruding length
120 mm
Name Identifying order number
A25 06280
OAL Overall length
188.4 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN69871B
