Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A06 40160

A06 40160

A06 40160 A06 40160 A06 40160

A06 40160

Komet Group
Артикул: 1474751
В наличии
В корзину
Описание
Характеристики
BD Body diameter
63 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
01
CCONWS Connection count workpiece side
1
CCSWS Connection code style
5
CCTWS Connection code type
ABS
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0630
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DF Flange diameter
80 mm
DIN
HSK08000195
FamilyProducts
Adaptor ABS 63
HAND Cutting direction
N - Neutral
ID Technical product number
1474751
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
59 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ABS KOMET ABS connection
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0630
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ABS06300115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0800
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK08000195
LPR Protruding length
85 mm
Name Identifying order number
A06 40160
OAL Overall length
125 mm
PENDP Pendulum property
0 - Without
Rotation Rotation indicator
1 - rotating tool
RPMX Rotational speed maximum
10000 1/min
STDNO Standard
DIN69893-1
WT Weight of item
2.2 kg
