Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric A06 30060

A06 30060

A06 30060 A06 30060 A06 30060

A06 30060

Komet Group
Артикул: 1486296
В наличии
В корзину
Описание
Характеристики
BD Body diameter
63 mm
BD Body diameter 2
56 mm
CCFWS Connection code form
02
CCSWS Connection code style
5
CCTWS Connection code type
ABS
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0630
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DF Flange diameter
63 mm
DIN
HSK06300195
FamilyProducts
Adaptor ABS 63N
HAND Cutting direction
N - Neutral
ID Technical product number
1486296
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
40 mm
LB Length 2
14 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ABS KOMET ABS connection
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0630
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ABS06300215
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR Protruding length
80 mm
Name Identifying order number
A06 30060
OAL Overall length
112 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN69893-1
WT Weight of item
1.64 kg
