Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 75A.41.13030

75A.41.13030

75A.41.13030

75A.41.13030

Komet Group
Артикул: 1500700
В наличии
В корзину
Описание
Характеристики
BD Body diameter
17 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SWK
CCUWS Connection code unit base
9
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0220
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ZYL02000115
FamilyProducts
REAMAX TS DAH Zero Halter kurz
HAND Cutting direction
N - Neutral
ID Technical product number
1500700
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SWK Quick change adapter KOMET
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0220
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SWK02200110
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
66974
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LPR Protruding length
78.5 mm
LSCN Clamping length minimum
0 mm
Name Identifying order number
75A.41.13030
OAL Overall length
125 mm
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN 1835 A
WT Weight of item
0.3 kg
