Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 301309 M10X25

301309 M10X25

301309 M10X25 301309 M10X25 301309 M10X25

301309 M10X25

Hoffmann Group
Артикул: 301309 M10X25
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SAD
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/11/2017
DF Flange diameter
63.55 mm
DIN
SKG04001795
FamilyProducts
GARANT Arbor for screw-in milling cutters with thread
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
44.1 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SAD Screw mounting
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAD01000115
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
HOG-T10
LOC-03 CCFMS Connection code form
17
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04001795
LPR Protruding length
44.1 mm
Name Identifying order number
301309 M10X25
OAL Overall length
112.5 mm
STDNO Standard
301309 M10X25
WT Weight of item
0.75 kg
Диаметр корпуса (BD) / Body diameter (BD)
18 mm
