Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 2.837963080

2.837963080

2.837963080 2.837963080

2.837963080

Kennametal
Артикул: 2.837963080
В наличии
В корзину
Описание
Характеристики
BD Body diameter
27.7 mm
BLQ Balance quality code
G2.5
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0080
DCONWS Diameter
8 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/17/2016
DIN
HSK06300595
FamilyProducts
HYDRAULIC CHUCK HC
ID Technical product number
2.837963080
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
26 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0080
LOC-01 DCONWS Diameter
8 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL00800115
LOC-02 DCONWS Diameter
8 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
KH-BSFF27.7
LOC-03 CCFMS Connection code form
05
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300595
LPR Protruding length
60 mm
Name Identifying order number
2.837963080
Rotation Rotation indicator
1 - rotating tool
TCDCON ISO-tolerance class connection bore diameter
h6
