Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 2.837063250

2.837063250

2.837063250 2.837063250

2.837063250

Kennametal
Артикул: 2.837063250
В наличии
В корзину
Описание
Характеристики
BD Body diameter
49.6 mm
BD Body diameter 2
63 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/17/2016
DIN
HSK06300195
FamilyProducts
HYDRAULIC EXPANSION CHUCK
ID Technical product number
2.837063250
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
51 mm
LB Length 2
94 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL02500115
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
KH-BVTX41125
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR Protruding length
120 mm
Name Identifying order number
2.837063250
Rotation Rotation indicator
1 - rotating tool
