Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 2.830050160

2.830050160

2.830050160 2.830050160

2.830050160

Kennametal
Артикул: 2.830050160
В наличии
В корзину
Описание
Характеристики
BD Body diameter
37.6 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0160
DCONWS Diameter
16 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG05001715
FamilyProducts
HYDRAULIC EXPANSION CHUCK
ID Technical product number
2.830050160
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
46.5 mm
LB Length 2
62.9 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0160
LOC-01 DCONWS Diameter
16 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
KH-BSFF37.6
LOC-02 DCONWS Diameter
16 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
KH-BVNC16
LOC-03 CCFMS Connection code form
17
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05001715
LPR Protruding length
82 mm
Name Identifying order number
2.830050160
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN69871
