Главная Каталог продукции Toolunited 15 401-01 - Converter, rotationally symmetric 2.830040060

2.830040060

2.830040060 2.830040060

2.830040060

Kennametal
Артикул: 2.830040060
В наличии
В корзину
Описание
Характеристики
BD Body diameter
25.7 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0060
DCONWS Diameter
6 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG04001715
FamilyProducts
HYDRAULIC EXPANSION CHUCK
ID Technical product number
2.830040060
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
33 mm
LB Length 2
52.9 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0060
LOC-01 DCONWS Diameter
6 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
KH-BSFF25.7
LOC-02 DCONWS Diameter
6 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
KH-BVNC6
LOC-03 CCFMS Connection code form
17
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04001715
LPR Protruding length
72 mm
Name Identifying order number
2.830040060
Rotation Rotation indicator
1 - rotating tool
STDNO Standard
DIN69871
