Главная Каталог продукции Toolunited 15 303-07 - Die end mill F4AL0800M0630 KC637M

F4AL0800M0630 KC637M

Артикул: F4AL0800M0630KC637M

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

8 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/4/2011

FamilyProducts

F4AL-MODULAR-SCREW-ON-HEAD

FHA Flute helix angle

30 Degree

GRDMFG Grade manufacturers designation

KC637M

ID Technical product number

F4AL0800M0630KC637M

Interface codes

ISYC Subclass

303-07 - Die end mill

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 DCONMS Diameter

8 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LPR Protruding length

18 mm

LS Shank length

15 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

Name Identifying order number

F4AL0800M0630 KC637M

OAL Overall length

33 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
