Главная Каталог продукции Toolunited 15 303-09 - Thread end mill STMD2L06015L062-I0.40ISO PC9070M

STMD2L06015L062-I0.40ISO PC9070M

Артикул: 6-01-020562

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KOR - Korloy

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

1.55 mm

Delivery state valid from

6/4/2014

DIN

ZYL00600105

FamilyProducts

ISO Metric - Deep Threading for Hard Materials (~HrC62)

GRDMFG Grade manufacturers designation

PC9070M

HAND Cutting direction

R - Right

ID Technical product number

6-01-020562

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LN Neck length

6.6 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

STMD2L06015L062-I0.40ISO PC9070M

OAL Overall length

76 mm

THFT Thread form type

TP Thread pitch

0.4 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
